• State-of-the-Art. Ergonomic design, 7" capacitive touch LCD display, and intuitive user interface sets a new industry standard.
• Status Indicator. LED light indicates status visible from anywhere in the workshop.
• Best In Class Serviceability. New ergonomic hinged service door simplifies unit service.
• Automatic Updates. Permanent wireless software updates, ensuring you always have the latest features.
• Oil System Management. Automatic weighing of recovered oil with on-board oil-injection allows accurate replenishment of oil removed during service.
• UV Dye Injection. Integrated UV dye injection provides high level of A/C system leak detection.
• Remote Support for Technicians. Allows MAHLE to connect to a unit over WiFi for troubleshooting and advanced support.
• Data Management & Reporting Metrics. Ability to log and monitor services allowing analytics for proactive service reminders, refrigerant use optimization, warranty reporting and more.
• Customer Service. Every unit is built to be easily repaired by the owner and we proudly offer nationwide service centers and lifetime phone support coverage and a two year standard warranty.
• Network Printing. Retains valuable service records, network printing capability to print services provided for customer.
• Manufacturer Warranty: 2 Years Parts, 1 Year Labor

Optional Features (Not Included):

• Thermal Printer. Allows printing of service reports.
• Refrigerant Identifier. Prevents contamination of machine internals.
• Smart. iOS and Android capable phone app allowing remote service session mirroring and advanced functions.

• Certifications: SAE J2788, SAE J2099, UL 1963
• Charge Performance: +/- 0.5 oz. at 70° to 75°F (+/- 15g at 21° to 24°C)
• Recovery Performance:  95% at 70° to 75°F (21° to 24°C) within 30 minutes
• Operation: Fully Automatic
• Charging Cylinder: 30 lb. (13.6 kg) DOT
• Compressor: 3/8 HP-0.279kW
• Dimensions (H x W x D):47 in x 29 in x 29 in (119 cm x 74 cm x 74 cm)
• Weight:  215 lb. (98 kg)
• Display:  Color, 7” Capacitive Touch Screen
• Filter Drier Capacity: 150 lb. (68 kg) spin-on type
• Hoses: 9 ft. (2.75 m)
• Languages: English, French, Spanish
• Operating Ranges: 50° to 122° F (10° to 50° C)
• Power Source: 120 VAC - 60 HZ - 12 AMP
• Printer: Optional
• Vacuum Pump: 2 CFM dual stage
