• Fully welded frame for maximum strength and durability
• Double-speed pump for improved efficiency
• Foot control air valve allows effortless, hands-free operation of air motor
• Cylinder can be moved left or right to apply pressure exactly where it's needed
• Self-locking hand winch for easier raising and lowering of the press bed
• 8 Position bed allows work height adjustment of 4" each
• Large oil-filled anti-shock pressure gauge with stainless steel frame scale for US and metric tons
• Patented safety valve for longer service life
• Includes a set of non-slip steel blocks for safer operation
• Includes protective work guard for added safety
• Meets or exceeds ASME/PASE 2019 standards

Specifications:

• Capacity: 75 Tons
• Hydraulic stroke: 9.88"
• Working Range: 6.63" to 34.75"
• Horizontal Ram Travel: 10.25"
• Bed width: 31.5"
• Bed depth: 10.9"
• Bed inner dimensions (effective area): 9.9"
• Bed Positions: 8
• Press Size: 51.2" W x 31.5" D x 74.63" H
• Air Pressure: 110 to 120 psi
